Capacity
Up to 84
Exterior Width
96"
Interior Width
90 3/4"
Aisle Width
Varies by floor plan
Skirt Length
19 3/4", 25 3/4"
Alternator
210, 240, 270 and 320 amps with 12 volts
Brakes
4-channel antilock brake system; Air drum and air disc brakes available
Wheelbase
189"/217"/245"/259"/273"
Overhang
Front: 95" with standard steel bumper; Rear: varies by body length/wheelbase
Fuel Capacity
SAE Type III Composite wrapped aluminum located outboard of frame within wheelbase and inboard of frame in rear overhang; SCF @ 70F/3600PSI, 7692; DGE, 55 - GGE, 62
Rear Axle
Rear axle with hypoid, single reduction gears with broad range of ratios available to optimize powertrain performance (Rating varies by capacity)
Tire Size
11R22.5 (G) all-position radials
Entrance Door
32" Wide x 79" High/ Double electric outward opening (air optional)
Rear Door
Emergency window standard
Transmission
Allison 2500 PTS – 5 & 6 speed automatic; Allison 3000 PTS – 5 & 6 speed automatic
Engine
Cummins L9N 250-280 hp
Interior Height
77"
Overall Height
122″ – 128″ excluding roof options
Suspension
Steering
Tilting & telescoping steering column
Front Axle
Ratings vary by capacity
Battery Capacity
3 group 31 batteries, each battery is 12v, 700CCA (2100 CCA combined) 185 minutes of reserve capacity
Wheel Cut
50 Degrees
GVWR
Up to 36,200 lbs.
