Capacity
Up to 77
Exterior Width
96"
Interior Width
90 3/4"
Aisle Width
Varies by floor plan
Skirt Length
16 1/4", 19 3/4", 25 3/4"
Alternator
210, 240, 280, and 325 amps with 12 volts
Brakes
4-wheel hydraulic disc brakes with 4-channel anti-lock brake system; Air drum and air disc brakes available
Wheelbase
169″/189″/217″/238″/252″/273″/280″
Overhang
Front: 45″ with standard steel bumper; Rear: varies by body length/wheelbase
Fuel Capacity
Standard: 67 gallon* Optional: 93-gallon located between frame rails in rear *47-gallon for 169” wheelbase
Rear Axle
27” wide x 78” high/double electric outward opening
Tire Size
11R-22.5(G) all - position radials
Entrance Door
27” wide x 78” high/double electric outward opening
Rear Door
37" wide x 52" high
Transmission
Ford® 6R140 – 6-speed automatic
Engine
Ford® 7.3L with ROUSH CleanTech Liquid Propane Autogas Fuel System, 335 hp
Interior Height
77"
Overall Height
122″ – 128″ excluding roof options
Suspension
Steering
Tilting & telescoping steering column
Front Axle
Ratings vary by capacity
Battery Capacity
2 group 31 batteries, each battery rated at 12v, 700CCA & 185 minutes of reserve capacity
Wheel Cut
50 Degrees
GVWR
Up to 33,000 lbs.
